中恒IMPS00216 (48V60A )嵌入式通信开关电源
产品说明
中恒电源IMPS00216 (48V60A )嵌入式通信开关电源 IMPS00216，中恒嵌入式电源48V60A
产品介绍 中恒电源IMPS00216系列嵌入式通信电源系统采用先进的模块设计使得整个系统体积很小，却能提供足够的功率满足通信系统的要求，同时符合机架式安装的特征。系统操作方便，易于安装和维护；整流模块与监控模块采用插箱式安装方式，便于灵活扩容和更换。 主要特点 * 超宽范围电网交流输入，工作范围宽至90～290Vac。 技术参数
Zhongheng power supply imps00216 (48v60a) embedded communication switching power supply imps00216, Zhongheng embedded power supply 48v60a Product introduction The imps00216 series embedded communication power supply system of Zhongheng power supply adopts advanced module design, which makes the whole system small in size, but can provide enough power to meet the requirements of communication system and meet the characteristics of rack mounting. The system is easy to operate, easy to install and maintain; the rectifier module and monitoring module adopt plug-in installation mode, which is convenient for flexible expansion and replacement. It is suitable for SPC exchange, transmission equipment, data communication, mobile communication, railway communication, satellite communication, microwave communication and other communication equipment. Product specification: Optional specification of rectifier module: 48V / 30A Optional specifications of monitoring module: A-type monitoring (with display), C-type monitoring (without display) Frame optional specification: rear outlet main features *Ultra wide range AC input of power grid, working range of 90 ~ 290vac. *The rectifier module adopts active power factor compensation technology, and the power factor value reaches 0.98. *The rectifier module adopts full bridge soft switching technology, and the efficiency can reach more than 92%. *The current sharing n + 1 redundancy modular design is adopted to ensure the safe and stable operation of the load. *Rectifier module adopts non-destructive hot plug technology, plug and play. *Perfect battery management. Under load power and battery low-voltage protection, can achieve temperature compensation, automatic floating charge control and so on. *The network design provides RS485 communication interface and fault dry contact interface, which can realize local and remote monitoring. *Perfect lightning protection design for AC and DC sides, suitable for areas with thunderstorms. *Complete fault alarm and fault protection functions. *Standard 19 inch 2U rack mount, full front operation and maintenance. technical parameter Product parameter specification Zhongheng power imps00216 system configuration Rectifier module 2×48V/30A Monitoring module Type a monitoring (with LCD) Wiring mode Rear outlet Load interface 1 way Battery interface 1 way Rack height 19 inch 1U rack type input Rated input voltage 220Vac，50Hz Input voltage range 90V-280Vac power factor zero point nine eight output Output voltage range 42-58Vdc Output floating charge voltage 53.5Vdc Output equalizing charging voltage 56.5Vdc Maximum output current 60A 60A Output efficiency ≥92%% Insulation class Insulation strength Input output 3000vdc / 10mA / 1min Input - housing 2500vdc / 10mA / 1min Output - housing 700vdc / 10mA / 1min insulation resistance When the ambient temperature is 25 ± 5 ℃, the relative humidity is 90%, and the test voltage is 500V DC, the power input pair The insulation resistance of output, input to ground and output to ground shall not be less than 10m Ω, and leakage current shall be less than 3.5ma Usage environment working temperature -20-50°C humidity Relative humidity 10% - 90%, non solidification protect Protection function Input under voltage / over-voltage protection, output under voltage / over-voltage protection, battery power down protection, overload protection, short-circuit protection Mechanics Dimensions (width, height and depth) 482×88×350mm 华为通信电源,华为高频开关电源,华为直流电源,华为电源柜,华为-48v开关电源,华为电源官网,华为通信电源柜,华为开关电源柜,华为r48,华为mts9000A,华为etp48,华为tp48,华为5g电源,华为整流模块,华为ups,华为osn,华为传输,华为波分,华为optix |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
